MPN: 3257 | Recessed Frameless Waste Receptacle

• CABINET: 22 gauge stainless steel with exposed surfaces in architectural satin finish. Welded construction with seamless corners and burr-free edges
• DOOR: 18 gauge stainless steel. 13mm return for maximum rigidity. The concealed full-length stainless steel piano hinge and tumbler lock are keyed like other Bradley units.
• PUSH FLAP DOOR: 22 gauge stainless steel with exposed surfaces in architectural satin finish. Heavy-duty stainless steel piano hinge
• WASTE RECEPTACLE INSERT: leakproof moulded plastic - Capacity 10.60 Litres

Operation

The waste receptacle insert is removable by unlocking the cabinet door.

Installation & Dimensional Detail

Verify all rough-in dimensions before installation. The recessed unit requires a rough wall opening 309mm W x 663mm H x 102mm D. Secure to framing with mounting screws (included) at the holes provided. Shim at the screw points as required. See the technical data sheet.
